CBS350-8T-E-2G | Thiết bị chuyển mạch Cisco 8 cổng Gigabit, 2 cổng Combo Gigabit(RJ-45 và SFP)

Tình trạng: Còn hàng Thương hiệu: Cisco

Giá: 0₫

Số lượng:

Chia sẻ:

Chính sách bán hàng

Cam kết 100% chính hãng

Miễn phí giao hàng

Hỗ trợ 24/7

Thông tin thêm

Hoàn tiền 111% nếu hàng giả

Mở hộp kiểm tra nhận hàng

Đổi trả trong 7 ngày

Khuyến mãi dành cho bạn

Miễn phí vận chuyển

Đơn hàng từ 1,000,000 VNĐ

Mã: A87TYRT55

HSD: 10/05/2023

Giảm 3%

Đơn hàng từ 4,000,000 VNĐ

Mã: QH5G8J0Y

HSD: 05/05/2023

Mở rộng BH đến 2 năm

Chỉ cần cộng thêm 500,000 VNĐ cho 1 SP

Mã: FT45YUO8H

HSD: 10/05/2023

Giảm 5%

Khi mua đơn hàng thứ 2 (Giá trị từ 5,000,000 VNĐ)

Mã: A789UYT

HSD: 20/05/2023

Mô tả sản phẩm

Giới thiệu chung:

Switch Cisco CBS350-8T-E-2G cung cấp sự kết hợp lý tưởng giữa chi phí và hiệu năng cho văn phòng nhỏ, hỗ trợ 8 port 10/100/1000 và 2 cổng uplink combo copper/SFP.

Thông số kỹ thuật:

Performance
Capacity in Millions of Packets per Second (mpps) (64-byte packets)	14.88
Switching Capacity in Gigabits per Second (Gbps)	20.0
Layer 2 Switching	Spanning Tree Protocol Port grouping/link aggregation - Up to 8 groups - Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregationVLAN - Support for up to 4,094 VLANs simultaneously - Port-based and 802.1Q tag-based VLANs; MAC-based VLAN; protocol-based VLAN; IP subnet-based VLAN - Management VLAN - Private VLAN with promiscuous, isolated, and community port - Private VLAN Edge (PVE), also known as protected ports, with multiple uplinks - Guest VLAN, unauthenticated VLAN - Dynamic VLAN assignment via RADIUS server along with 802.1x client authentication - CPE VLAN Voice VLAN Multicast TV VLAN VLAN Translation Q-in-Q Selective Q-in-Q Generic VLAN Registration Protocol (GVRP)/Generic Attribute Registration Protocol (GARP) Unidirectional Link Detection (UDLD) Dynamic Host Configuration Protocol (DHCP) Relay at Layer 2 Internet Group Management Protocol (IGMP) versions 1, 2, and 3 snooping IGMP Querier Head-of-Line (HOL) blocking Loopback DetectioN
Layer 3	IPv4 routing - Wirespeed routing of IPv4 packets - Up to 990 static routes and up to 128 IP interfaces IPv6 routing Layer 3 Interface - Configuration of Layer 3 interface on physical port, Link Aggregation (LAG), VLAN interface, or loopback interface Classless Interdomain Routing (CIDR) Policy-Based Routing (PBR) DHCP Server DHCP relay at Layer 3 User Datagram Protocol (UDP) relay
Security	Secure Shell (SSH) Protocol Secure Sockets Layer (SSL) IEEE 802.1X (Authenticator role) Web-based authentication STP Bridge Protocol Data Unit (BPDU) Guard STP Root Guard STP loopback guard DHCP snooping IP Source Guard (IPSG) Dynamic ARP Inspection (DAI) IP/MAC/Port Binding (IPMB) Secure Core Technology (SCT) Secure Sensitive Data (SSD) Trustworthy systems Private VLAN Layer 2 isolation Private VLAN Edge (PVE) with community VLAN Port security RADIUS/TACACS+ RADIUS accounting Storm control DoS prevention Multiple user privilege levels in CLI ACLs Support for up to 1,024 rules
Management	Web user interface SNMP Remote Monitoring (RMON) IPv4 and IPv6 dual stack Firmware upgrade Port mirroring VLAN mirroring DHCP (options 12, 66, 67, 82, 129, and 150) Secure Copy (SCP) Autoconfiguration with Secure Copy (SCP) file download Text-editable config files Smartports Auto Smartports Textview CLI Cloud services Embedded Probe for Cisco Business Dashboard Cisco Network Plug and Play (PnP) agent Localization Login banner Other management
Power consumption
System Power Consumption	110V=12.55W 220V=12.56W
Power Consumption (with PoE)	N/A
Heat Dissipation (BTU/hr)	42.86
Hardware
Total System Ports	10 Gigabit Ethernet
RJ-45 Ports	8 Gigabit Ethernet
Combo Ports(RJ 45 + Small form-factor pluggable [SFP])	2 Gigabit Ethernet combo
Console port	Cisco Standard mini USB Type-B / RJ45 console port
USB slot	USB Type-A slot on the front panel of the switch for easy file and image management
Buttons	Reset button
Cabling type	Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T
LEDs	System, Link/Act, PoE, Speed
Flash	256 MB
CPU	800 MHz ARM
Packet buffer	1.5 MB
Environmental
Unit dimensions (W x H x D)	268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)
Unit weight	1.7 kg (3.75 lb)
Power	100-240V 50-60 Hz, external
Certification	23° to 122°F (-5° to 50°C)
Storage temperature	-13° to 158°F (-25° to 70°C)
Operating humidity	10% to 90%, relative, noncondensing
Storage humidity	10% to 90%, relative, noncondensing
Acoustic noise and Mean Time Between Failure (MTBF)
FAN	Fanless
Acoustic Noise	N/A
MTBF at 25°C (hours)	2,171,669
